IPC322LB-SF28(40)-A | UNV 2MP Vandal-resistant Network IR Fixed Dome Camera
IPC322LB-SF28(40)-A | UNV 2MP Vandal-resistant Network IR Fixed Dome Camera
gallery
gallery

IPC322LB-SF28(40)-A | UNV 2MP Vandal-resistant Network IR Fixed Dome Camera

• High quality image with 2MP, 1/2.8"CMOS sensor
• 2MP (1920*1080)@30/25fps; 720P (1280*720)@30/25fps
• Ultra 265, H.265, H.264
• Smart IR, up to 30m (98ft) IR distance
• Day/night functionality
• 2D/3D DNR (Digital Noise Reduction)
• IP67 protection
• IK10 vandal resistant
• Support PoE power supply
• 2-Axis

Download

Product Specification

 IPC322LB-SF28-AIPC322LB-SF40-A
Camera
Sensor1/2.8", progressive scan, 2.0 megapixel, CMOS
Lens2.8mm@F2.04.0mm@F2.0
DORI DistanceLens (mm)Detect (m)Observe (m)Recognize (m)Identify (m)
2.843.417.48.74.3
4.062.124.812.46.2
Angle of View (H)106.7°87.5°
Angle of View (V)57.1°46.3°
Adjustment anglePan: 3° ~ 360°Tilt: 0° ~ 75°
ShutterAuto/Manual, 1 ~ 1/100000s
Minimum IlluminationColour: 0.01Lux ( F2.0, AGC ON)
0Lux with IR
Day/NightIR-cut filter with auto switch (ICR)
Digital noise reduction2D/3D DNR
S/N>52dB
IR RangeUp to 30m (98ft) IR range
Wavelength850nm
IR On/Off ControlAuto/Manual
DefogDigital Defog
WDRDWDR
Video
Video CompressionUltra 265, H.265, H.264
H.264 code profileBaseline profile, Main profile, High profile
Frame RateMain Stream: 1080P (1920*1080), Max 30fps; 720P (1280*720), Max 30fps
Sub Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps;
Video Bit Rate128 Kbps~16 Mbps
OSDUp to 4 OSDs
Privacy MaskUp to 4 areas
ROIUp to 8 areas
Motion DetectionUp to 4 areas
White BalanceAuto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital noise reduction2D/3D DNR
Smart IRSupported
FlipNormal/Vertical/Horizontal/180°
DewarpingN/A
HLCSupported
BLCSupported
Network
ProtocolsIPv4, IGMP, ICMP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, UPnP, HTTP
Compatible IntegrationAPI
ClientEZStation
EZView
EZLive
Web BrowserPlug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+
Interface
Network10/100M Base-TX Ethernet
Certifications
CertificationsCE: EN 60950-1
UL: UL60950-1
FCC: FCC Part 15
General
PowerDC 12V±25%, PoE (IEEE 802.3af)
Power consumption: Max 5.0W
Dimensions (Ø x H)Φ109 x 81mm (Ø4.3” x 3.2”)
Net Weight0.35kg (0.77lb)
MaterialMetal + Plastic
Working Environment-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Strorage Environment-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Surge Protection4KV
Ingress ProtectionIP67
Vandal ResistantIK10
Reset ButtonN/A
